TEP 75-7212WI
Manufacturer:
TRACO Power
Mfr.Part #:
TEP 75-7212WI
Datasheet:
Description:
Board Mount Modules 61.00mmL×57.90mmW×12.70mmH Through Hole Current - Output 1:6.3 A Voltage - Output 1:12 V 91 %
| Parameter | Value |
|---|---|
| Length | 61 mm |
| Width | 57.9 mm |
| Max Operating Temperature | 75 °C |
| Min Operating Temperature | -40 °C |
| Height | 12.7 mm |
| Packaging | Box |
| Depth | 12.7 mm |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Weight | 97 g |
| Features | Remote On/Off, OTP, OVP, SCP, UVLO |
| Min Input Voltage | 43 V |
| Output Current | 6.3 A |
| Output Voltage | 12 V |
| Max Output Current | 6.3 A |
| Max Input Voltage | 160 V |
| Number of Outputs | 1 |
| Isolation Voltage | 2.25 kV |
| Output Power | 75 W |
| Current - Output 1 | 6.3 A |
| Efficiency | 91 % |
| Voltage - Output 1 | 12 V |
| Max Input Voltage (DC) | 160 V |
| Nominal Output Voltage | 12 V |
| Nominal Input Voltage | 72 V |
| Max Output Power | 75 W |
| Min Input Voltage (DC) | 43 V |
